• Reasonable layout, high integration and small footprint;
• Centralized control of electric, pneumatic and hydraulic systems with world-renowned components;
• Designs as per API 4F specification, finite element analysis and stress test of the mast guarantee the safety effectively;
• The chassis with excellent off-road performance and driving performances adopts heavy-duty axles, low-section tires, high-strength frame and dual braking system, durable and suitable for complicated oilfield conditions;
• Multiple optional configurations are available such as new cab, mast automatic locking pin, centralized lubrication system of crown block and drawworks, and engine hood for various climates.
Model | XJ700 | XJ900 | XJ1100 | XJ1350 | XJ1600 | XJ1800 | XJ2250 |
---|---|---|---|---|---|---|---|
Rated Hook Load (lb/kN) | 150000(700) | 200000(900) | 240000(1100) | 300000(1350) | 350000(1600) | 400000(1800) | 500000(2200) |
Service Depth (2-7/8”Tubing) (ft/m) | 10500(3200) | 13100(4000) | 18000(5500) | 23000(7000) | 28000(8500) | - | - |
Nominal Drilling Depth (2-7/8”Drill Pipe) (ft/m) | 6,500(2,000) | 10,500(3,200) | 14,700(4,500) | 19,000(5,800) | 23,000(7,000) | 26,200(8,000) | 30,000(9,000) |
Drawworks Power (HP/kW) | 280(208) | 360(269) | 460(343) | 525(391)/575(429) | 650(485) | 460(343)×2 | 600(448)×2 |
Lines | 6 | 6 | 8 | 8 | 8 | 10 | 10 |
Wireline Diameter (in/mm) | 7/8(22) | 1(26) | 1(26) | 1(26) | 1 1/8(29) | 1 1/4(32) | 1 1/4(32) |
Mast Height (ft/m) | 69(21) | 104(31.7) | 105(32) | 108(33) | 115(35) | 118 / 125(36 / 38) | 125(38) |
Chassis Drive | 6×6 | 8×8 /10×8 | 10×8 | 10×8 | 12×8 | 14×8 | 14×10 |
